Захищає чутливу електроніку від пошкоджень, спричинених надмірними високочастотними перешкодами.
| Body | Brass | Gold 1u"/Nickel/Copper |
| Insulator | PEI | N/A |
| Contact Pin | Beryllium Copper | Gold 5u"/Nickel/Copper |
| Shell | Aluminum | N/A |
| Impedance | 50 Ω | |
| Voltage Rating | N/A | |
| Frequency Range | 10 MHz – 67 GHz | |
| Dielectric Withstanding Voltage | N/A | |
| Contact Resistance (Center) | N/A | |
| Contact Resistance (Outer) | N/A | |
| Insulation Resistance | N/A | |
| Return Loss | > 8 dB | |
| Insertion Loss | N/A | |
| Force to Engage and Disengage | N/A | |
| Center Contact Retention Force | N/A | |
| Coupling Nut Retention Force | > 60 lbs | |
| Coupling Nut Proof Torque | > 15 in-lbs | |
| Durability | > 500 cycles | |
| Temperature Range | -40 °C ~ +100 °C | |
